Frozen dehumidifier is what we usually say dehumidifier, professionally called frozen dehumidifier, the basic principle is that water vapor meets cooling copper fin cold water droplets, in the entire liquefaction process dehumidifier is a device that provides gaseous water into liquid water.

Of course, the entire dehumidification process of the cryodehumidifier is subdivided into two cycle processes, the inner cycle and the outer cycle, so as to achieve the conversion of energy and follow the conservation law of energy, and finally complete the dehumidification process of the entire specific space.

The external circulation of the cryodehumidifier is divided into three processes, di one process is to suck the room temperature humid air into the machine through the fan, the second process is to suck the water vapor in the room temperature humid air through the evaporator (cooling copper tube and fin) into water droplets, and discharge through the hose. The third process is that the dry air cooled by the evaporator is heated to normal temperature through the condenser (high temperature copper tube and fin) and discharged through the outlet, so that the air is dehumidified.

The whole process also follows the law of conservation of energy, and the air also goes through a cycle process of normal temperature - low temperature - normal temperature, which is also a process of energy conversion.

The inner cycle of the cryodehumidifier, the compressor sucks in the low-temperature and low-pressure refrigerant gas (commonly known as fluorine) and compresses it into a high-temperature and high-pressure gas, and the high-temperature and high-pressure gas passes through the condenser (copper tube and fin).

So the copper tube is very hot, for air heating) heat into a medium temperature and high pressure gas, medium temperature and high pressure gas through the capillary throttling into low temperature and low pressure liquid, low temperature and low pressure liquid through the evaporator (copper tube and fin, this time the copper tube is low temperature, for room temperature humid air cooling let water vapor liquefaction precipitation) into low temperature and low pressure gas, Then it is compressed into high temperature and high pressure gas by the compressor, and so reciprocating to form an internal cycle.
